Overview
Configured for 24 VDC power distribution and field-side termination, the Honeywell MU-TLPA02 51304467-100 (MU-TLPA02 Power Adapter Terminal Assembly) provides direct electrical connection between the incoming DC supply and associated control hardware. The assembly supports a maximum current capacity of 5 A and operates within a defined industrial temperature and humidity range.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MU-TLPA02 51304467-100 |
| Base Model | MU-TLPA02 |
| Brand | Honeywell |
| Product Type | Power Adapter Terminal Assembly |
| Origin | USA |
| Spare Model | 51304467-100 |
| Power Input | 24 VDC |
| Maximum Current Capacity | 5 A |
| Operating Temp | -10 deg C to 60 deg C |
| Storage Temp | -40 deg C to 85 deg C |
| Humidity Tolerance | 5% to 95% non-condensing |
| Weight | 0.3 kg |
| Dimensions | Estimated shipping size: 15.1 x 12 x 5 cm |
| Power Consumption | Not specified; load capacity is 5 A maximum |
| Tariff Code | 8537101190 |
| Place of Shipment | Xiamen, China |
Honeywell DCS Power Interface Characteristics
The MU-TLPA02 is a power-interface assembly rather than an analog or discrete signal acquisition module. Therefore, its primary electrical function concerns DC supply routing and termination.
The specified input is 24 VDC, while the maximum stated current capacity is 5 A. Consequently, connected equipment must remain within the available current rating.
The assembly does not have a documented 4-20 mA HART signal specification in the supplied data. Therefore, HART loop communication should be handled by the applicable Honeywell I/O hardware rather than attributed to this terminal assembly.
For DCS installations, maintain appropriate separation between DC power conductors and low-level instrumentation wiring. Where shielded signal cables are present, apply the system grounding design specified for the associated Honeywell control architecture rather than using the power terminal as an assumed signal reference.
Frequently Asked Questions
Q: What DC supply does the MU-TLPA02 require?
A: The specified power input is 24 VDC.
Q: What is the maximum current capacity of the MU-TLPA02?
A: The supplied specification states a maximum current capacity of 5 A.
Q: Does the supplied specification confirm hot-swap operation?
A: No. The supplied data does not specify hot-swap capability. Follow the applicable system maintenance procedure before disconnecting or replacing the assembly.
Field Installation Guidelines
- Verify that the incoming supply is 24 VDC before connecting the assembly.
- Confirm that the connected load remains within the 5 A maximum current capacity.
- De-energize the applicable circuit before performing terminal wiring or removal unless the system documentation explicitly permits energized work.
- Route DC power wiring separately from low-level analog and communication cables where practical.
- Maintain correct polarity throughout the 24 VDC power circuit.
- Secure conductors to prevent mechanical stress at the terminal connection.
- Use the control-system grounding and shielding scheme specified for the associated Honeywell installation.
- Do not exceed the stated operating temperature range of -10 deg C to 60 deg C.
- Protect the assembly from condensation because the specified humidity tolerance is 5% to 95% non-condensing.
- After installation, verify supply voltage, polarity, terminal integrity, and connected-load current before returning the circuit to service.
