Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 8200-1302 |
| Module Type | Digital Governor Turbine Control – Process Control Outlet |
| Primary Function | Turbine speed, load, and process control |
| Input Signals | 4–20 mA, 0–10 V, digital logic signals |
| Output Signals | Analog 4–20 mA, digital relay outputs |
| Network Interface | Compatible with Woodward NetCon and Micronet systems |
| Operating Temperature | –40°C to +70°C |
| Power Supply | 24 VDC nominal |
| Diagnostics | Internal monitoring and status indicators |
| Mounting | Rack-mounted or panel integration |
| Compliance | CE, UL listed, suitable for industrial rotating-equipment environments |
| Response Time | Optimized for rapid load and speed changes |
| Typical Applications | Steam/gas turbines, load-sharing, generator synchronization, process control |
| Key Benefits | High-precision control, fast response, reliable operation, seamless integration |
FAQ
A1: It is compatible with most steam and gas turbines using Woodward digital governors.
Q2: Can it manage multiple turbine systems simultaneously?
A2: Yes, the module supports load-sharing and synchronization across multiple generators.
Q3: What type of inputs and outputs does it support?
A3: The module supports analog 4–20 mA, 0–10 V, and digital logic signals.
Q4: How does it improve operational safety?
A4: Built-in diagnostics, status indicators, and fail-safe outputs ensure reliable turbine control.
Q5: Is it suitable for retrofitting existing turbine systems?
A5: Yes, it integrates seamlessly into legacy Woodward digital control networks.
Q6: What environmental conditions can the module withstand?
A6: It operates reliably between –40°C and +70°C, even in harsh industrial environments.
