Overview
Configured for PROFIBUS DP gateway communication, the Honeywell CC-IP0101 51410056-175 (CC-IP0101 PROFIBUS DP Gateway Module) provides physical and electrical data exchange between the connected PROFIBUS network and the host control system.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-IP0101 51410056-175 |
| Spare Model | 51410056-175 |
| Product Type | PROFIBUS DP Gateway Module |
| Brand | Honeywell |
| Origin | USA |
| Shipment Location | Xiamen, China |
| Weight | 0.4 kg |
| Dimensions | 5.5 x 15.5 x 14.5 cm estimated shipping size |
| Operating Temp | -20 deg C to +60 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Humidity | 5-95% RH, non-condensing |
| Supply Voltage | 24 VDC +/-10% |
| Current Consumption | <=150 mA idle; <=500 mA full load |
| Isolation | 500 VAC |
| Maximum Nodes | 125 nodes per segment |
| Connector | 9-pin D-sub or terminal block |
| PROFIBUS Type | PROFIBUS DP |
| Tariff Code | 8537101190 |
PROFIBUS DP Communication Characteristics
The CC-IP0101 operates as a PROFIBUS DP gateway module and handles cyclic industrial network data between the PROFIBUS DP segment and the associated control architecture. The module supports up to 125 nodes per segment according to the supplied specification.
The 24 VDC supply accepts a +/-10% tolerance, while current consumption varies from 150 mA during idle operation to 500 mA at full load. Therefore, the control-system power budget should account for the maximum stated current.
The module provides 500 VAC isolation. This isolation separates the relevant electrical interfaces and helps limit the transfer of unwanted electrical potential between connected circuits.
For network termination and field wiring, the module accepts either a 9-pin D-sub connection or a terminal block. Consequently, installers should select the connector arrangement that matches the installed PROFIBUS DP wiring architecture.
Frequently Asked Questions (FAQ)
Q: What network protocol does the CC-IP0101 support?
A: The CC-IP0101 is specified as a PROFIBUS DP gateway module and supports PROFIBUS DP network communication.
Q: What supply voltage does the module require?
A: The module operates from a 24 VDC supply with a stated tolerance of +/-10%.
Q: What is the specified current consumption?
A: Current consumption is <=150 mA during idle operation and <=500 mA under full load.
Field Installation Guidelines
- Verify the module model and spare model before installation: CC-IP0101 and 51410056-175.
- Confirm that the available supply provides 24 VDC within the specified +/-10% tolerance.
- Provide sufficient power capacity for the stated full-load current of 500 mA.
- Install and terminate the PROFIBUS DP wiring according to the applicable network installation requirements.
- Use the specified 9-pin D-sub or terminal block connection as appropriate for the installed hardware.
- Maintain appropriate separation between communication wiring and high-voltage or high-current conductors to reduce electrical interference.
- Connect cable shielding according to the grounding design of the control system and PROFIBUS installation.
- Verify polarity, connector seating, and field wiring before energizing the module.
- Keep the installation environment within -20 deg C to +60 deg C and 5-95% RH non-condensing during operation.
- Confirm that the PROFIBUS segment does not exceed the specified maximum of 125 nodes per segment.
