Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 8406-003 |
| Module Type | Dual Display Control Panel |
| Display Type | Two high-contrast LCD screens with backlight and adjustable brightness |
| Display Resolution | 320 x 240 pixels per display |
| Input Signals | Supports analog (4–20 mA) and digital signals compatible with Woodward control systems |
| Input Voltage Range | 0–30 VDC for digital inputs; 4–20 mA for analog inputs |
| Output Signals | Relay outputs, configurable logic outputs, and communication outputs for control and alarms |
| Relay Rating | 2 A @ 30 VDC / 0.5 A @ 120 VAC |
| Communication Interface | RS-485, Modbus RTU, Micronet, NetCon compatible |
| Power Requirements | 24 VDC nominal, 0.5 A typical, 1 A maximum |
| Operating Temperature | –20°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Relative Humidity | 5%–95% non-condensing |
| Mounting | Panel or rack-mounted installation |
| Dimensions (HxWxD) | 210 mm x 180 mm x 120 mm (8.3” x 7.1” x 4.7”) |
| Weight | 2.5 kg (5.5 lbs) |
| Indicators | Alarm, status, and power LEDs; user-configurable for system events |
| Compliance | CE marked, UL listed |
| Typical Applications | Turbine and generator monitoring, industrial process control, combined-cycle power plants |
| Response Time | < 50 ms for digital signal processing |
| Update Rate | 1–10 Hz configurable for real-time monitoring |
| Environmental Rating | IP20 indoor, with optional IP54 front panel protection |
| Redundancy Support | Supports dual-redundant communication channels for high-availability systems |
| Configuration | User-configurable via front panel or software interface |
FAQ
A1: The panel features two high-contrast LCD screens with adjustable backlight for clear visibility in all lighting conditions.
Q2: Which input signals are supported by this control panel?
A2: It supports analog inputs (4–20 mA) and digital inputs compatible with Woodward control systems.
Q3: Can the 8406-003 communicate with other Woodward systems?
A3: Yes, it is compatible with Micronet, NetCon, and Modbus RTU communication networks.
Q4: What are the operating temperature limits for the panel?
A4: The panel operates safely between –20°C and +70°C, suitable for most industrial environments.
