Overview
Specification
| Parameter | Description |
|---|---|
| Model | 5501-365 |
| Manufacturer | Woodward |
| Module Type | Governor MPU & I/O Module |
| Function | Microprocessor-based control with digital and analog I/O |
| Inputs | Multiple digital and analog inputs for sensors and controllers |
| Outputs | Digital and analog outputs for actuators and control signals |
| Power Supply | 18–32 VDC nominal |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Communication | MicroNet digital interface |
| Diagnostics | Status LEDs for inputs, outputs, and system health |
| Mounting | Rack or panel-mount in compatible Woodward systems |
| Dimensions | Approx. 260 mm × 160 mm × 35 mm |
| Weight | Approx. 1.2 kg |
FAQ
A1: It provides microprocessor-based control with integrated digital and analog I/O for governor systems.
Q2: Can it handle both digital and analog signals?
A2: Yes, the module supports multiple analog and digital inputs and outputs for full system control.
Q3: Is it compatible with other Woodward MicroNet modules?
A3: Yes. It integrates seamlessly with MicroNet digital control systems and other Woodward modules.
Q4: How does it enhance system reliability?
A4: Its robust construction, diagnostics, and modular design minimize downtime and optimize process stability.
Q5: What are the operating conditions for the module?
A5: It operates between 0°C and +60°C and withstands storage temperatures from -40°C to +85°C.
