Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 9907-162 |
| Module Type | Digital Governor Turbine Control Module |
| Function | Regulates turbine speed, load, and power output |
| Input Voltage | 24–28 VDC nominal, 20–32 VDC operating range |
| Current Draw | 100 mA typical, 200 mA maximum |
| Operating Temperature | –40°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Speed Regulation Accuracy | ±0.25% of full-scale speed |
| Response Time | <50 ms typical to step changes |
| Analog Inputs | 4–20 mA, 0–10 V for speed reference and process feedback |
| Digital Inputs | 24 VDC logic for start/stop, trip, and mode selection |
| Output | 4–20 mA actuator signal, optional digital interface |
| Mounting | Panel or rack-mountable |
| Communication | Compatible with NetCon and Micronet protocols |
| Environmental Protection | Vibration-resistant and EMI/EMC shielded for industrial use |
| Indicators | LED status indicators for power, fault, and operational mode |
| Diagnostics | Built-in self-test and operational monitoring |
| Redundancy / Safety Features | Supports dual-redundant turbine configurations and fault-tolerant operation |
| Dimensions | 6.5 x 4.0 x 2.2 inches (approximate) |
| Weight | 0.9 lb (0.41 kg) |
| Certifications | CE compliant, UL recognized component |
FAQ
A1: Yes, it is backward-compatible with many legacy Woodward turbine systems.Q2: What communication protocols are supported?
A2: The module supports NetCon and Micronet for integration with control networks.
Q3: Is it suitable for harsh industrial environments?
A3: Yes, the 9907-162 is vibration-resistant and EMI/EMC shielded for industrial use.
