Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 5503-198 |
| Module Type | Versatile MicroNet Remote I/O Module |
| I/O Channels | Configurable discrete and analog inputs/outputs |
| Communication Interface | WOODWARD MicroNet network |
| Power Supply | 24 VDC nominal, 0.5–1 A typical |
| Operating Temperature | 0°C to +70°C |
| Storage Temperature | –40°C to +85°C |
| Humidity | 5–95% RH non-condensing |
| Mounting | Rack-mounted or panel-mounted |
| Status Indicators | LEDs for power, health, and I/O activity |
| Diagnostics | Built-in monitoring for health, network, and I/O status |
| Response Time | < 5 ms typical for discrete I/O channels |
| Electrical Protection | Over-voltage, short-circuit, and isolation protection on I/O lines |
| Regulatory Compliance | CE certified, UL recognized component |
| Dimensions | 7 x 2.5 x 5 inches (rack module size) |
| Application Environment | Industrial engines, turbines, and complex automation systems |
FAQ
A1: It provides remote input/output control for MicroNet-based industrial automation systems.
Q2: Can this module handle harsh industrial conditions?
A2: Yes, it is designed to tolerate vibration, temperature changes, and electrical noise.
Q3: How is the module status monitored?
A3: Integrated LEDs show power, health, and I/O activity for immediate feedback.
Q4: What types of I/O does it support?
A4: It supports both discrete and analog inputs/outputs for versatile system integration.
