Overview
Specification
| Specification | Details |
|---|---|
| Product Type | Power Supply Module |
| Brand | Schneider Electric |
| Series | Modicon Quantum |
| Model | 140CPS11420 |
| Input Voltage | 115 V AC (93–138 V), 230 V AC (170–276 V) |
| Input Current | 1100 mA at 115 V, 600 mA at 230 V |
| Inrush Current | 38 A at 115 V, 19 A at 230 V |
| Rated Power | 130 VA |
| Associated Fuse Rating | 2 A, slow-blow |
| Harmonic Distortion | ≤10 % of fundamental RMS value |
| Output Voltage | 5.1 V DC |
| Output Current | 11 A at 60 °C standalone, 10 A redundant |
| Output Overvoltage Protection | Internal |
| Output Overload Protection | Internal |
| Power Dissipation | 6 + (1.5 × Iout) W, where Iout in A |
| Alarm Output | 1 NC, 6 A 220 V for power supply fault |
| Local Signalling | 1 LED (green) for power (PWR OK) |
| Bus Current Requirement | 600 mA per channel |
| Module Format | Standard Quantum rack module |
| Net Weight | Approx. 0.65 kg |
| Certifications | CE, UL, CUL, FM Class 1 Division 2, CSA C22.2 No 142 |
| Operating Temperature | 0…60 °C |
| Storage Temperature | -40…85 °C |
| Relative Humidity | 95 % without condensation |
| Isolation Voltage | 500 V DC |
FAQ
Q: Is the 140CPS11420 brand new and original?
A: Yes, the 140CPS11420 is 100% original from Schneider Electric.
Q: How fast can this power supply be shipped?
A: We maintain stock for immediate dispatch. Delivery typically occurs within 3 days to 2 weeks depending on order quantity.
Q: Which shipping carriers are available?
A: We commonly use DHL, UPS, and FedEx for safe and timely delivery.
Q: What if the module has a quality issue?
A: We support a 30-day return policy for any quality-related concerns.
Q: Can this module provide redundant power for Quantum systems?
A: Yes, the 140CPS11420 supports both standalone and redundant operation with stable output.
