Overview
Specification
| Category | Specification |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Analog Input Module |
| Input Channels | 8 isolated channels |
| Input Signal Types | ±10 V, 0…20 mA, 4…20 mA |
| Resolution | 15 bits + sign |
| Conversion Time | ≤ 1 ms per channel |
| Measurement Error | ≤ 0.2% of full scale (0…60 °C), 0.1% (25 °C) |
| Temperature Drift | 45 ppm/°C (±10 V, 0…20 mA, 4…20 mA) |
| Crosstalk Attenuation | ≥ 80 dB |
| Common Mode Rejection | 100 dB |
| Isolation Voltage | 1400 V DC (channel ↔ bus / ground), 750 V DC (between channels) |
| Status Indicators | 1 Green LED (RUN), 1 LED per channel, 1 Red LED (ERR), 1 Red LED (I/O) |
| Fallback Mode | Configurable / Predefined |
| MTBF Reliability | 1,000,000 hours |
| Operating Altitude | 0…2000 m (normal), up to 5000 m with derating |
| Dimensions (H x W x D) | 32 x 100 x 86 mm |
| Net Weight | 0.16 kg (0.35 lb US) |
FAQ
Yes, we only supply brand-new and factory-sealed Schneider Modicon X80 BMXAMI0810 modules.Q2: How fast can you ship the BMXAMI0810 module?
We ship within 3 days to 2 weeks depending on order size, using trusted couriers like DHL.
Q3: Does the BMXAMI0810 support both current and voltage inputs?
Yes, it accepts ±10 V, 0–20 mA, and 4–20 mA input ranges across its 8 isolated channels.
Q4: What happens if the module fails after installation?
We provide a 30-day return policy for quality-related issues.
Q5: What is the weight and size of the BMXAMI0810?
It weighs only 0.16 kg and measures 32 x 100 x 86 mm, making installation simple.
