Overview
The Honeywell 51120841-101, by Honeywell, qualifies as a Single SPDT (Single Pole Double Throw) control relay for TDC3000 series systems. It provides switching of one circuit between two outputs and includes features aiding status visibility and durability.
Specification
| Parameter | Value / Typical for Similar Relays |
|---|
| Manufacturer | Honeywell |
| Model Number | 51120841-101 |
| Relay Type | Single SPDT that switches common between normally open and normally closed |
| Coil Voltage | 24 VDC (verify in datasheet) |
| Contact Rating | ~ 10 A at resistive load (typical for single SPDT relays) |
| LED Indicator | Yes — indicates coil energization |
| Connector / Terminals | Screw terminals or suitable panel connectors |
| Size / Footprint | Approximate dimension typical of small panel relay modules |
| Weight | Typically under 0.5 lb (~0.2 kg) |
| Operating Environment | Industrial ambient temperature range (approx -20 °C to +70 °C) |
| System/Application | Legacy Honeywell TDC3000 control / safety systems |
