Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-GDOL11 51306321-175 |
| Brand | Honeywell |
| Origin | USA |
| Product Type | Digital Output GI/IS IOTA |
| System Platform | Experion PKS Series C / C300 |
| Module Function | High-Integrity Digital Output Termination Assembly |
| Channel Count | 16 Digital Output Channels |
| Output Voltage | 24 VDC nominal |
| Maximum Output Current | 0.5 A per channel |
| Signal Type | Discrete ON/OFF digital output |
| Isolation Type | Galvanic isolation, channel-to-channel and channel-to-system |
| Intrinsic Safety Interface | GI/IS field termination support |
| Diagnostics | Short-circuit monitoring and overload detection |
| Mounting Type | Series C Carrier / DIN Rail mounting |
| Weight | 0.45 kg approximate |
| Operating Temp | 0 deg C to +55 deg C |
| Power Consumption | Not specified in supplied data |
| Humidity Range | 5% to 95% RH, non-condensing |
Honeywell Process Control Isolation and Field Interface Technology
The CC-GDOL11 applies Honeywell Series C I/O architecture for direct field device switching and electrical separation. Therefore, the module maintains isolation between controller-side logic circuits and external loads such as solenoid valves, relays, alarms, and contactors.
The module supports channel-to-channel isolation to reduce interference caused by field wiring faults. In addition, the galvanic isolation structure limits transient electrical propagation toward the Experion PKS controller hardware.
For process instrumentation environments, Honeywell I/O assemblies commonly maintain signal integrity through controlled field interfaces. The CC-GDOL11 follows this design approach by providing isolated discrete output paths instead of direct controller-to-load wiring.
Frequently Asked Questions
Q: Does the CC-GDOL11 support direct connection to 24 VDC field devices?
A: Yes. The module provides 24 VDC discrete output channels for compatible field devices within the Experion PKS Series C I/O architecture.
Q: What isolation functions are provided by the CC-GDOL11?
A: The module provides galvanic isolation between field channels and the controller system, including channel-to-channel electrical separation.
Q: Can the CC-GDOL11 operate as a standalone digital output module?
A: No. The module requires installation within the Honeywell Series C / C300 I/O system hardware configuration.
Field Installation Guidelines
Install the CC-GDOL11 on the specified Honeywell Series C carrier assembly and verify the mechanical locking position before energizing the system.
Use approved field wiring practices for digital output circuits. Keep signal wiring separated from high-voltage power cables to reduce electrical interference.
Connect cable shields according to the plant grounding standard. Avoid multiple grounding points that may create unwanted ground loops.
Verify field load ratings, polarity, and terminal assignments before applying 24 VDC power. Confirm controller configuration and I/O channel mapping before commissioning.
Follow Honeywell Experion PKS engineering documentation for firmware compatibility, controller assignment, and maintenance procedures.
.
