Overview
The Honeywell CC-TAID01 is a 16-channel differential analog input module designed for integration with the Experion® PKS Series C system. This module enables precise measurement of various analog signals, including voltage and current inputs, and is ideal for applications requiring high accuracy and reliability in industrial environments.
Each relay delivers a dry contact for isolated low-voltage/low-current or high-voltage/high-current discrete output applications. Users configure the relay output as Form A or Form B via jumpers. The Relay IOTA connects with the Digital Output 24V (DO24V) IOM through a dedicated IOTA to support Relay functionality. The module fully incorporates all characteristics of the DO24V IOM while enhancing output flexibility.The Analog Input Module accepts high level current or voltage inputs from transmitters and sensing devices.
Specification
| Specification | Details |
|---|---|
| Model | CC-TAID01 |
| Type | 16-Channel Differential Analog Input Module |
| Compatibility | Experion PKS Series C |
| Input Ranges | 0–10 V, 4–20 mA, 0–5 V, 1–5 V |
| Input Impedance | High impedance |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Isolation | 500 Vrms |
| Sampling Rate | User-configurable |
| Power Supply | 24 VDC |
| Mounting Type | DIN rail |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% RH, non-condensing |
| Dimensions (L x W x H) | 305 mm x 90 mm x 30 mm |
| Weight | Approximately 0.5 kg |
