Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-HCN911 51307206-175 |
| Brand | Honeywell |
| Product Type | Series C Control Module |
| Origin | USA |
| Weight | 0.44 kg |
| Dimensions | 6.1 x 16.2 x 14.6 cm |
| Operating Temp | -20 deg C to +70 deg C |
| Power Consumption | 10 W output power |
| Operating Voltage | 24 VDC |
| Input Current | 1.5 A |
| Output Frequency | 1 kHz |
| Humidity Range | 5% to 95% non-condensing |
| Tariff Code | 8537101190 |
| Spare Model | 51307206-175 |
Process Control Signal Interface Characteristics
The Honeywell CC-HCN911 Series C Control Module operates within Series C control architectures and manages electrical control functions through defined module power and signal interfaces. Therefore, system engineers should verify backplane compatibility, addressing configuration, and firmware support before installation.
The module uses a 24 VDC operating supply with a 1.5 A input current rating. Furthermore, the hardware provides a 10 W output power capability and supports a 1 kHz output frequency for connected control functions.
For Honeywell process control environments, engineers should consider channel-to-channel isolation requirements, loop signal integrity, and grounding practices when integrating field-connected devices. The installation design should maintain proper separation between power wiring and low-level signal wiring to reduce electrical interference.
Frequently Asked Questions
Q: What power supply specification does the CC-HCN911 require?
A: The CC-HCN911 operates with a 24 VDC supply and requires an input current of 1.5 A.
Q: What environmental conditions support CC-HCN911 operation?
A: The module supports an operating temperature range from -20 deg C to +70 deg C and humidity from 5% to 95% non-condensing.
Q: Does the CC-HCN911 require specific installation considerations?
A: Yes. Installation should follow Series C rack requirements, maintain correct module seating, and apply proper grounding and cable routing practices.
Field Installation Guidelines
- Confirm that the Series C chassis configuration matches the CC-HCN911 module requirements before installation.
- Verify the 24 VDC power source polarity and electrical rating before connecting the module.
- Install the module with proper mechanical alignment to ensure correct backplane contact.
- Separate control signal wiring from high-current power cables to reduce electromagnetic interference.
- Connect grounding points according to Honeywell system installation procedures.
- Inspect connectors and terminal interfaces for contamination or mechanical damage before commissioning.
- Verify module status indicators and system diagnostics after power application.
