Overview
Configured for I/O signal extension within a Honeywell control system, the Honeywell FS-TERM-0001 (FS-TERM-0001 IO Extender Module) provides a 16-point interface for DI, DO, AI, and AO signal types. The module operates from a specified 24 VDC input range of 18-36 V and provides 1500 V AC isolation.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | FS-TERM-0001 |
| Brand | Honeywell |
| Product Type | IO Extender Module |
| Origin | USA |
| Weight | 0.2 kg |
| Dimensions | 12 x 8.5 x 6 cm shipping size |
| Operating Temp | -40 deg C to +70 deg C |
| Storage Temp | -50 deg C to +85 deg C |
| Input Voltage | 24 VDC, 18-36 VDC |
| Power Consumption | 2.5 W typical |
| Isolation | 1500 V AC |
| Channel Capacity | 16 points |
| Signal Types | DI, DO, AI, AO |
| Humidity | 5-95% RH, condensing |
| Space Requirements | 4 TE, 3 HE (4 HP, 3U) |
| Power Requirements | 5 VDC, 35 mA |
| Ripple Content | Less than 50 mV p-p |
| Approvals | CE, TUV, UL, CSA, FM |
| Tariff Code | 8537101190 |
Process I/O Signal Interface
The FS-TERM-0001 provides a 16-point signal interface covering digital input, digital output, analog input, and analog output signal types. The available signal categories support connection between field-side wiring and the associated control-system I/O architecture.
The specified 1500 V AC isolation separates the relevant electrical interface paths. The 24 VDC input specification defines an operating range from 18 VDC to 36 VDC. The module also specifies a 5 VDC, 35 mA power requirement, which should be checked against the applicable Honeywell chassis or system power architecture before installation.
Frequently Asked Questions
Q: How many I/O points does the FS-TERM-0001 support?
A: The module has a specified capacity of 16 points and supports DI, DO, AI, and AO signal types.
Q: What supply voltage does the FS-TERM-0001 specify?
A: The specified input voltage is 24 VDC, with an operating range of 18-36 VDC. The technical data also lists a 5 VDC, 35 mA power requirement for the module interface.
Q: What environmental conditions are specified for operation?
A: The operating temperature range is -40 deg C to +70 deg C. Storage temperature is -50 deg C to +85 deg C, with humidity specified at 5-95% RH, condensing.
Field Installation Guidelines
- Verify the module model and terminal assignment against the applicable Honeywell system documentation before wiring.
- Confirm the available supply voltage remains within the specified 18-36 VDC range.
- Verify the required 5 VDC, 35 mA system power interface before inserting or energizing the module.
- Install the module within the specified 4 TE, 3 HE (4 HP, 3U) mechanical space.
- Route signal wiring separately from high-current power conductors where practical to reduce electrical interference.
- Maintain correct polarity and terminal identification for all connected I/O circuits.
- Connect cable shields according to the grounding scheme specified for the host Honeywell system.
- Check isolation requirements before connecting circuits that operate at different reference potentials.
- Confirm the installed environment remains within the specified temperature and humidity limits.
- Inspect wiring and terminal seating before applying power to the module
