Overview
Configured for universal input/output signal handling in Honeywell Safety Manager SC hardware, the Honeywell FC-TUIO52 (FC-TUIO52 Universal Input/Output Module) provides direct physical and electrical I/O execution. The module is SIL 3-rated and operates from a 24 VDC power supply. Its specified input voltage range is 0-30 VDC, with an output current range of 5 A to 16 A.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | FC-TUIO52 |
| Brand | Honeywell |
| Product Type | Universal Input/Output Module |
| System | Safety Manager SC Hardware |
| Safety Rating | SIL 3-rated |
| Origin | USA |
| Weight | 0.4 kg |
| Dimensions | 19.1 x 18.8 x 6.5 cm |
| Operating Temp | -20 deg C to +60 deg C |
| Power Supply | 24 VDC |
| Input Voltage Range | 0-30 VDC |
| Output Current | 5 A to 16 A |
| Tariff Code | 8537101190 |
Safety Manager SC I/O Characteristics
The FC-TUIO52 is specified as Safety Manager SC hardware with a SIL 3 rating. The module accepts electrical input conditions within the stated 0-30 VDC range and provides an output current range of 5 A to 16 A.
The 24 VDC supply defines the module power interface. Therefore, installation should maintain the specified supply polarity, voltage level, and wiring separation required by the associated Safety Manager SC hardware.
The supplied specifications do not define individual channel counts, channel isolation values, signal conversion characteristics, communication protocols, or response times. These parameters should be confirmed against the applicable Honeywell system documentation before commissioning.
Frequently Asked Questions
Q: What supply voltage is specified for the FC-TUIO52?
A: The specified power supply is 24 VDC.
Q: What input voltage range does the FC-TUIO52 support?
A: The specified input voltage range is 0-30 VDC.
Q: What operating temperature range is specified?
A: The specified operating range is -20 deg C to +60 deg C.
Field Installation Guidelines
Install the FC-TUIO52 according to the mechanical and electrical requirements of the associated Honeywell Safety Manager SC hardware.
Verify the 24 VDC supply before connecting field wiring. Confirm that the applied input signals remain within the specified 0-30 VDC range.
Route power and I/O wiring according to the system cabinet wiring practice. Keep signal wiring separated from high-energy conductors where required to reduce electrical interference.
Terminate shields and protective conductors according to the approved cabinet grounding design. Do not introduce unverified grounding paths through field signal wiring.
Before energization, verify terminal identification, wiring polarity, conductor integrity, and the compatibility of connected field devices. Confirm the complete system configuration and applicable safety documentation before placing the module into service.
