Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-TAOX11 |
| Spare Model | 51308353-175 |
| Brand | Honeywell |
| Product Type | Analog Output Module |
| System Platform | Honeywell Experion PKS Series C |
| Signal Type | HART Analog Output |
| Output Current | 0.46 A |
| Power Supply | 24 VDC |
| Origin | USA |
| Weight | 0.36 kg |
| Dimensions | 29.4 x 12 x 6.3 cm |
HART Analog Output Loop Interface
The Honeywell CC-TAOX11 processes analog output signals through HART communication loops within the Experion PKS Series C architecture. Furthermore, the module supports current loop connections for field devices that require controlled analog output signals.
The module design follows Honeywell DCS I/O practices, including signal conditioning and channel-level interface functions. Therefore, field wiring requires correct polarity, shielding, and grounding practices to maintain signal integrity.
Frequently Asked Questions
Q: What type of field signal does the CC-TAOX11 handle?
A: The CC-TAOX11 is a HART analog output module designed for analog current output signal interfaces in Honeywell Experion PKS Series C systems.
Q: Does the CC-TAOX11 require a 24 VDC supply?
A: Yes. The provided specification identifies the module power requirement as 24 VDC.
Q: Can the CC-TAOX11 be installed without considering cable shielding?
A: No. Field installation should follow industrial analog signal wiring practices, including proper shield termination and separation from high-voltage cables.
Field Installation Guidelines
Install the CC-TAOX11 according to Honeywell Experion PKS Series C I/O cabinet installation requirements.
- Verify the module position and terminal assignment before connecting field wiring.
- Use shielded cables for analog output loops and terminate shields according to the control cabinet grounding design.
- Separate analog signal cables from power conductors and high-frequency switching lines.
- Confirm 24 VDC supply polarity before energizing the module.
- Check field device loop resistance and wiring continuity before commissioning.
- Follow Honeywell documentation for rack mounting, terminal connections, and system configuration procedures.
