Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-TCF901 51308301-175 |
| Brand | Honeywell |
| Product Type | Control Firewall Input/Output Termination Assemblies |
| System Platform | Honeywell Experion PKS Series C |
| Origin | USA |
| Weight | 0.18 kg |
| Dimensions | Estimated shipping size: 14.5 x 12 x 5.3 cm |
| Operating Temp | -40 deg C to +85 deg C |
| Power Consumption | Approximately 1 W |
| Form Factor | SFP optical module |
| Fiber Type | Medium single-mode glass fiber |
| Fiber Specification | 9/125 um |
| Optical Wavelength | 1300 nm |
| Maximum Transmission Distance | 15 km (9 miles) |
| Connector Type | LC connector |
| Supply Voltage | 3.3 V |
| Interface Function | Fiber optic communication interface |
Fiber Optic Communication and Control Network Integration
The CC-TCF901 provides a single-mode fiber interface for Honeywell control firewall communication assemblies. Moreover, the module converts electrical communication signals into optical transmission signals through an SFP form factor.
The optical interface uses 9/125 um single-mode glass fiber with a 1300 nm wavelength. Therefore, the module supports long-distance communication links while maintaining signal transmission performance across industrial network infrastructure.
In addition, the LC connector design simplifies fiber installation within compatible termination assemblies. The 3.3 V operating supply supports integration with Honeywell control system hardware requiring compact optical communication components.
Honeywell Industrial Network Fiber Interface Features
The CC-TCF901 supports industrial communication architectures that require fiber-based data transmission between control system components. Moreover, the fiber connection reduces the impact of electromagnetic interference commonly present near industrial equipment.
The module operates across a wide industrial temperature range from -40 deg C to +85 deg C. Therefore, it can support installations where environmental temperature variations require extended operating capability.
The SFP optical design allows standardized module integration within compatible Honeywell communication assemblies. In addition, fiber isolation helps separate communication paths from electrical noise sources and potential grounding differences.
Frequently Asked Questions
Q: What fiber type does the Honeywell CC-TCF901 use?
A: The CC-TCF901 uses medium single-mode glass fiber with a 9/125 um specification.
Q: What is the maximum communication distance supported by CC-TCF901?
A: The module supports a maximum optical transmission distance of 15 km (9 miles).
Q: What connector type does the CC-TCF901 fiber interface use?
A: The module uses an LC optical connector for fiber connection.
Field Installation Guidelines
Install the CC-TCF901 module only in compatible Honeywell control firewall termination assemblies according to system documentation.
Verify the fiber type and connector specification before installation. Avoid sharp bends, excessive pulling force, or contamination on optical connector surfaces during fiber handling.
Clean LC connectors before connection to reduce optical signal loss. Moreover, maintain proper fiber routing separation from high-voltage power cables and strong electromagnetic interference sources.
Confirm the optical link status after installation through the associated Honeywell system diagnostics. Check communication indicators and verify correct network configuration before returning the system to normal operation.
