Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-PCF901 51405047-175 |
| Brand | Honeywell |
| Product Type | FTE Control Firewall Module |
| System Platform | Honeywell Experion PKS |
| Origin | USA |
| Weight | 0.3 kg |
| Dimensions | 6 x 15.5 x 14.5 cm (estimated shipping size) |
| Operating Temp | 0 deg C to 50 deg C (typical) |
| Storage Temp | -20 deg C to 70 deg C |
| Power Consumption | 24 VDC power supply input (typical) |
| Number of Ports | 9 ports |
| Port Type | RS-485 / RS-232 compatible |
| Humidity Range | 5-95% RH, non-condensing |
| Tariff Code | 8537101190 |
Honeywell Process Communication and Isolation Features
The CC-PCF901 module operates as an FTE Control Firewall interface within the Honeywell Experion PKS communication architecture. It manages serial communication paths through nine available ports and provides controlled data routing between connected automation devices.
Furthermore, the module follows Honeywell process control communication design principles, including network segmentation and controlled access between system communication layers. The RS-485 and RS-232 compatible interfaces support connection with industrial serial devices where electrical isolation and communication management are required.
The module is designed for process automation environments where communication integrity, channel separation, and deterministic data exchange are required. It does not provide process measurement functions such as 4-20 mA HART input processing or FOUNDATION Fieldbus signal conditioning.
Frequently Asked Questions
Q: What communication interfaces are supported by the CC-PCF901 51405047-175?
A: The module supports RS-485 and RS-232 compatible communication connections through nine available ports.
Q: What power supply is required for the CC-PCF901 module?
A: The module typically operates from a 24 VDC power supply input. The installation must follow the Honeywell system power distribution requirements.
Q: Can the CC-PCF901 be installed as a standalone serial communication device?
A: The module is designed for integration within Honeywell Experion PKS FTE communication structures. Standalone operation depends on the connected system architecture and configuration.
Field Installation Guidelines
- Install the CC-PCF901 module inside an approved industrial control cabinet with proper mechanical protection.
- Verify the 24 VDC power supply polarity before connecting field wiring.
- Use shielded communication cables for RS-485 and RS-232 connections where required by the site grounding design.
- Connect cable shields according to the control cabinet grounding specification to reduce electrical noise interference.
- Separate communication wiring from high-current power cables to minimize electromagnetic coupling.
- Confirm port assignment and communication parameters before system commissioning.
- Inspect connector seating and terminal conditions during preventive maintenance activities.
