Overview
It integrates seamlessly within the Bently Nevada 3500 Series rack and supports demanding industrial monitoring environments.
Moreover, this module works directly with compatible position monitors to ensure accurate axial and radial position measurements.
Specification
| Category | Specification |
|---|---|
| Model Number | 135145-01 |
| Manufacturer | Bently Nevada |
| Product Series | 3500 Machinery Protection System |
| Module Type | Position I/O Module |
| Form Factor | Single-slot Eurocard module |
| Rack Compatibility | Bently Nevada 3500 rack |
| Number of Channels | 4 position input channels |
| Supported Signal Type | Position probe signals via compatible 3500 Position Monitors |
| Input Interface | Backplane interface to 3500 rack |
| Field Wiring Interface | Detachable terminal block connections |
| Backplane Connector Type | High-density edge connector |
| Internal Signal Conditioning | None, monitor-dependent processing |
| Energy Storage Components | None |
| Operating Voltage | Supplied internally by 3500 rack backplane |
| Power Consumption | Low-power design, rack-distributed supply |
| Isolation | System-level isolation through rack architecture |
| Dimensions (H × W × D) | Approx. 241.3 × 24.4 × 99.1 mm |
| Weight | Approx. 0.34 kg |
| Cooling Method | Passive cooling via rack airflow |
| Mounting Method | Slide-in rack mounting with locking retention |
| Operating Temperature Range | 0 °C to +65 °C |
| Storage Temperature Range | −40 °C to +85 °C |
| Relative Humidity | Up to 95%, non-condensing |
| Vibration Resistance | Designed for industrial machinery environments |
| Compliance | Meets Bently Nevada 3500 system specifications |
| Typical Applications | Turbines, compressors, pumps, large rotating machinery |
FAQ
Yes, the 135145-01 we supply is brand new, factory original, and fully genuine.
Q2: Do you keep this module in stock?
Yes, we maintain ready stock for the 135145-01 to support urgent project requirements.
Q3: How fast can you ship after ordering?
We ship within three days to two weeks, depending on order quantity and preparation requirements.
Q4: Which logistics services do you usually use?
We commonly ship the 135145-01 using DHL and other reliable international carriers.
Q5: Do you support returns if quality issues appear?
Yes, we support returns within 30 days if any verified quality issues occur.
