Overview
Specification
| Parameter | Description |
|---|---|
| Model Number | 3500/15 |
| Part Number | 133292-01 |
| Manufacturer | Bently Nevada (Baker Hughes) |
| Function | Legacy low-voltage DC power supply for the 3500 System |
| Input Voltage Range | 20 to 30 VDC |
| Input Power Consumption | Approximately 90 W |
| Output Voltages | +24 VDC, +15 VDC, –15 VDC, +5 VDC (regulated) |
| Output Power Capacity | Sufficient for powering a full rack of 3500 modules |
| Redundant Capability | Dual module configuration with automatic failover |
| Switchover Time | <20 milliseconds |
| Electrical Isolation | 1500 V RMS isolation between input and output |
| Indicators | OK (green), Power (green), Fault (red) |
| Cooling Method | Convection cooled, no fans required |
| Mounting Location | Leftmost rack position in the 3500 frame |
| Operating Temperature | 0°C to +65°C (32°F to +149°F) |
| Storage Temperature | –40°C to +85°C (–40°F to +185°F) |
| Humidity | Up to 95% non-condensing |
| Dimensions | Approx. 24.4 cm (H) × 3.8 cm (W) × 17.1 cm (D) |
| Weight | Approx. 1.1 kg (2.43 lb) |
| Compliance | CE, CSA, and IEC/EN 61010-1 |
| Maintenance | Annual inspection recommended |
| Warranty | Typically 2 years (varies by region/distributor) |
FAQ
A1: It operates with 20–30 VDC low-voltage inputs, typically from industrial power or UPS systems.
Q2: Can this module be used with AC input?
A2: No, this specific model is for DC input only. For AC input, use the 3500/15 127610-01 variant.
Q3: How does redundancy work in this system?
A3: Two modules can operate in parallel, and if one fails, the other instantly takes over without interruption.
Q4: How can I monitor the module’s status?
A4: The front-panel LEDs indicate power, OK, and fault conditions for quick visual inspection.
Q5: What is the main difference between the Legacy DC and standard DC power supplies?
A5: The Legacy version (133292-01) supports lower voltage DC input and is compatible with earlier 3500 rack designs.
