Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05‑02‑04‑00‑00‑00 |
| Product Type | System Rack for 3500 Machinery Protection Modules |
| Rack Size | 19‑inch EIA Rack, Full‑Size (14 module slots) or 12‑inch Mini-Rack (7 module slots) |
| Module Slots | 14 module slots (full-size) / 7 module slots (mini-rack) plus reserved power/interface positions |
| Mounting Options | Panel mount, Rack mount, Bulkhead mount (Full-Size); Panel mount (Mini-Rack) |
| Format Options | Full-size rack or mini-rack with flexible front or rear wiring access |
| Backplane Communication | High-speed integrated backplane for module communication |
| Power Distribution | Uniform distribution through the backplane |
| Compatible Modules | 3500 Series monitoring, interface, and power supply modules |
| Installation Flexibility | Supports front or rear access depending on mount type |
| Typical Environments | Control rooms, machinery protection centers, industrial cabinets |
| Build Quality | Engineered for industrial resilience and long service life |
FAQ
A1: It provides a centralized housing platform for 3500 monitoring modules and manages power distribution across them.Q2: How many slots are available in this rack?
A2: This full‑size rack accommodates 14 module slots plus reserved positions for power and interface modules.
Q3: What mounting options are supported?
A3: Panel mount, rack mount, and bulkhead mount formats support diverse installation needs.
Q4: Can the rack support system expansion later?
A4: Yes, its modular design allows additional modules without extensive rewiring.
Q5: Where is this rack typically installed?
A5: It fits 19‑inch industrial cabinets, machinery protection centers, and control rooms.
Q6: Does the system facilitate communication between modules?
A6: Yes, the integrated backplane enables efficient data exchange and system communication.
