| Parameter | Specification |
|---|---|
| Model Number | 3300/05‑22‑00‑00 |
| Product Type | 6 Slot Rack for 3300 XL NSv Proximity Transducers |
| Module Slots | 6 transducer module slots with reserved positions for power and interface |
| Rack Size | 19-inch industrial chassis |
| Mounting Options | Panel mount, Rack mount |
| Backplane Communication | High-speed integrated bus, supports real-time data transfer between modules |
| Power Distribution | Uniform power distribution to all module slots, short-circuit protected |
| Compatible Modules | 3300 XL NSv proximity transducer modules |
| Input Voltage | 24 VDC typical |
| Maximum Current per Slot | 500 mA |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Operating Humidity | 0 to 95% RH, non-condensing |
| Vibration Resistance | 5 g, 10–500 Hz |
| Shock Resistance | 30 g, 11 ms half-sine pulse |
| MTBF (Mean Time Between Failures) | >100,000 hours |
| Weight | ~6 kg |
| Dimensions (HxWxD) | 132 mm x 483 mm x 280 mm (approx.) |
| Typical Environments | Control rooms, machinery protection centers, industrial cabinets |
| Build Quality | Rugged, engineered for long service life and industrial reliability |
| Cooling | Convection cooled, no forced ventilation required |
| Installation Flexibility | Front or rear access, modular mounting |
| Safety Compliance | Meets CE and industrial EMC standards |
FAQ
A1: It organizes and powers up to six 3300 XL NSv modules while enabling high-speed data communication.Q2: How many modules can the rack accommodate?
A2: The system supports six proximity transducer modules with reserved slots for power and communication.
Q3: Can the rack be mounted in different ways?
A3: Yes. It supports both panel mount and standard 19-inch rack configurations.
Q4: What environments is it suitable for?
A4: It is designed for control rooms, machinery protection centers, and industrial cabinets.
Q5: Does it support high-speed data communication between modules?
A5: Yes. The integrated backplane ensures reliable communication across all module slots.
