Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3300/20‑13‑02‑01‑00‑00 |
| Product Type | Tachometer Module for 3300 XL NSv |
| Measurement Type | Rotational speed (RPM) |
| Compatible Systems | 3300 XL NSv Proximity Transducer Systems |
| Module Slots | Single-slot module |
| Output Signals | 4–20 mA analog output, optional relay alarms |
| Input Voltage | 24 VDC typical |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -55°C to +85°C |
| Operating Humidity | 0–95% RH, non-condensing |
| Vibration Resistance | 5 g, 10–500 Hz |
| Shock Resistance | 30 g, 11 ms half-sine |
| Accuracy | ±0.1% of full-scale RPM |
| Response Time | <50 ms |
| Weight | ~1.3 kg |
| Mounting Options | 3300 XL NSv standard rack or panel mount |
| Typical Environments | Control rooms, machinery protection centers, industrial cabinets |
| Build Quality | Rugged industrial design for continuous, reliable operation |
FAQ
A1: It measures rotational speed (RPM) and provides real-time monitoring for industrial machinery.
Q2: Which systems is it compatible with?
A2: Fully compatible with 3300 XL NSv proximity transducer systems.
Q3: What outputs does it provide?
A3: Provides 4–20 mA analog output and optional relay alarms for monitoring flexibility.
Q4: Can it operate in harsh industrial environments?
A4: Yes, it tolerates vibration, shock, and extreme temperature conditions.
