Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05‑01‑02‑05‑00‑01 |
| Product Type | System Rack for 3500 Machinery Protection Modules |
| Rack Size | 19-inch EIA Rack, Full-Size (14 module slots) |
| Module Slots | 14 module slots plus reserved power and interface positions |
| Mounting Options | Panel mount, Rack mount (mounts to 19-inch EIA Rack), Bulkhead mount |
| Format Options | Full-size rack with flexible front or rear wiring access |
| Backplane Communication | High-speed integrated backplane for module communication |
| Power Distribution | Uniform power distribution through the backplane |
| Compatible Modules | 3500 Series monitoring, interface, and power supply modules |
| Installation Flexibility | Supports front or rear access depending on mount type |
| Typical Environments | Control rooms, machinery protection centers, industrial cabinets |
| Build Quality | Engineered for industrial resilience and long service life |
FAQ
A1: It houses 3500 Series monitoring modules and distributes power uniformly across the system.Q2: How many modules can it support?
A2: This full-size rack supports 14 slots plus reserved positions for power and interface modules.
Q3: What mounting options are available?
A3: Panel mount, rack mount, and bulkhead mount formats support different installation needs.
Q4: Can the system be expanded later?
A4: Yes, its modular design allows adding or replacing modules without major rewiring.
Q5: Where is the rack typically installed?
A5: It fits industrial cabinets, control rooms, and machinery protection centers.
Q6: Does it support backplane communication?
A6: Yes, the integrated backplane allows high-speed communication between all modules.
