Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05‑02‑05‑00‑00‑01 |
| Product Type | System Rack for 3500 Machinery Protection Modules |
| Rack Size | 12-inch Mini-Rack with 7 module slots |
| Module Slots | 7 module slots plus reserved positions for power/interface |
| Mounting Options | Rack Mount, Mini-Rack |
| Format Options | Mini rack designed for compact industrial cabinets |
| Backplane Communication | Integrated communication bus for modules |
| Power Distribution | Uniform distribution to all modules |
| Compatible Modules | 3500 Series monitoring, interface, and power supply modules |
| Typical Environments | Compact control cabinets, machinery protection centers |
| Operating Voltage | 24 VDC typical |
| Operating Temperature | ‑40°C to +70°C |
| Power Consumption | Approx. 10 W |
| Weight | ~5.5 kg |
FAQ
A1: It houses and organizes 3500 Series modules while managing power and communication in a compact framework.
Q2: How many modules can this mini-rack support?
A2: It supports up to 7 modules plus reserved positions for power and interface functions.
Q3: What mounting options does this rack provide?
A3: This model uses a mini-rack format designed for rack mount installations.
Q4: Where is this rack typically installed?
A4: It fits compact control cabinets, industrial panels, and machinery protection centers.
Q5: Does it support data communication between modules?
A5: Yes. The integrated backplane allows high-speed communication across all module slots.
Q6: Can this rack be expanded in the future?
A6: Yes. Its modular design allows adding or replacing modules without extensive rewiring.
