Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05-01-01-05-00-01 |
| Product Type | System Rack for 3500 Machinery Protection Modules |
| Rack Size | 19-inch EIA Rack, Full-Size (14 module slots) |
| Module Slots | 14 monitoring module slots + dedicated power/interface positions |
| Mounting Options | Panel Mount, Rack Mount, Bulkhead Mount |
| Format Options | Full-size rack with flexible front or rear wiring access |
| Backplane Communication | High-speed integrated backplane for module-to-module communication |
| Power Distribution | Uniform power distribution through the backplane |
| Compatible Modules | All Bently Nevada 3500 Series monitoring and power modules |
| Installation Flexibility | Supports front-access or rear-access installation |
| Typical Environments | Control rooms, machinery protection centers, industrial cabinets |
| Build Quality | Heavy-duty industrial design for long-term reliability |
FAQ
A1: It houses 3500 Series machinery protection modules and distributes power across the system.Q2: How many module slots does it support?
A2: This full-size rack supports 14 module slots plus reserved left positions for power and interface modules.
Q3: What mounting options are available?
A3: Panel mount, rack mount, and bulkhead mount formats support various installation environments.
Q4: Can I expand my monitoring system later?
A4: Yes. The rack’s modular design lets you add or replace modules without rewiring major infrastructure.
Q5: Where is this rack typically installed?
A5: It fits 19-inch industrial cabinets, control rooms, and machinery protection systems.
Q6: Does it support backplane communication?
A6: Yes. The integrated backplane enables efficient data exchange among modules.
