Overview
This system rack ensures secure module placement through a front-loading design with locking retention, simplifying both installation and maintenance. Moreover, it integrates seamlessly with the 3500/22M Transient Data Interface and 3500/20 Rack Interface Module, ensuring full system communication and diagnostics.
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05-02-04-00-00-01 |
| Brand | Bently Nevada (GE) |
| Product Type | 3500 System Rack |
| Rack Size | 12-inch Mini-Rack (7 module slots) |
| Module Mounting | Front-loading with secure locking retention |
| Mounting Options | Panel Mount Option (Mini-Rack configuration) |
| Power Supply Options | Dual redundant AC or DC input |
| Communication Interface | Compatible with 3500/22M Transient Data Interface and 3500/20 Rack Interface Module |
| Backplane Design | Integrated signal and power distribution for module interconnection |
| Cooling Method | Natural convection (no external fan required) |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | Up to 95%, non-condensing |
| Dimensions (W × H × D) | Approx. 304.8 mm × 266.7 mm × 279.4 mm |
| Weight | Approx. 6.8 kg (fully equipped rack) |
| Material Construction | Aluminum chassis with cor |
FAQ
A: The Mini-Rack supports up to seven modules, while the Full-Size Rack accommodates up to fourteen. The Mini-Rack is ideal for limited-space installations.
Q2: Can the 3500/05-02-04-00-00-01 operate on both AC and DC power?
A: Yes, it supports dual redundant AC or DC power supplies for enhanced reliability.
Q3: Is this rack compatible with older 3500 modules?
A: Yes, it maintains backward compatibility with all standard 3500 series modules and interfaces.
Q4: How is cooling managed in this rack?
A: The system uses natural convection cooling, requiring no external fan.
