Overview
Engineered for long-term industrial reliability, the 3500/05 rack provides seamless module communication and efficient power distribution. Moreover, it integrates directly with the 3500/22M Transient Data Interface and 3500/20 Rack Interface Module, ensuring comprehensive system functionality and data connectivity.
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05-02-05-00-00-00 |
| Brand | Bently Nevada (GE) |
| Product Type | 3500 System Rack |
| Rack Size | 12-inch Mini-Rack (7 module slots) |
| Module Mounting | Front-loading with locking retention |
| Mounting Options | Rack Mount Option, Mini-Rack (mounts to 19-inch EIA Rack) |
| Power Supply Options | Dual redundant AC or DC input |
| Communication Interface | Compatible with 3500/22M Transient Data Interface and 3500/20 Rack Interface Module |
| Backplane Configuration | Integrated power and signal distribution |
| Cooling Method | Natural convection |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 95% non-condensing |
| Dimensions (W × H × D) | Approx. 304.8 mm × 266.7 mm × 279.4 mm |
| Material | Aluminum alloy chassis, corrosion-resistant coating |
| Weight | Approx. 6.8 kg (fully loaded) |
| Compliance | CE, CSA, ATEX/IECEx, ISO industrial standards |
| Reserved | None |
FAQ
A: The Mini-Rack holds seven modules and is optimized for smaller enclosures or localized monitoring points.
Q2: Can this rack operate with both AC and DC power?
A: Yes, it supports dual redundant AC or DC power supplies to enhance uptime.
Q3: Is the rack compatible with all 3500 series modules?
A: Absolutely. It supports full integration with all standard 3500 monitoring and interface modules.
Q4: What mounting options are available?
A: This model features a bulkhead mounting design suitable for Mini-Rack configurations.
Q5: How is the rack cooled?
A: It uses passive convection cooling, requiring no external fans or airflow systems.
