Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3300/05-24-00-00 |
| Product Type | XL NSv Proximity Transducer Rack |
| System Components | NSv Probe, Extension Cable, XL NSv Proximitor Sensor |
| Linear Range | 1.5 mm (60 mils) |
| Recommended Gap | 1.0 mm (40 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) ±12.5%/-20% |
| Deviation from Best Fit Line (DSL) | < ±0.06 mm (±2.3 mils) |
| Power Requirements | -17.5 Vdc to -26 Vdc, max 12 mA |
| Output Resistance | 50 Ω |
| Probe DC Resistance | 0.5–7 m: 4.0–5.9 Ω |
| Extension Cable Resistance | Center: 0.220 Ω/m; Shield: 0.066 Ω/m |
| Extension Cable Capacitance | 69.9 pF/m |
| Field Wiring | 0.2–1.5 mm² (16–24 AWG), shielded triad recommended |
| Max Field Wiring Length | 305 m (1,000 ft) |
| Operating Temperature | 0°C to +45°C (32°F to 113°F) |
| Environmental Tolerance | Industrial temperature and vibration resistant |
FAQ
A1: The recommended gap is 1.0 mm (40 mils) for accurate measurements.
Q2: Can this system replace older 3300 RAM Transducer Systems?
A2: Yes, it is fully compatible with 3300 RAM upgrades and certain 3000/7000-series systems.
Q3: What environmental conditions can it tolerate?
A3: It operates reliably in industrial temperature ranges and withstands vibration and EMI interference.
Q4: How long can the field wiring be?
A4: Field wiring can extend up to 305 meters (1,000 feet) using shielded triad cable.
Q5: What type of signals does it measure?
A5: Radial vibration, axial (thrust) position, tachometer, and phase reference signals.
