Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05‑02‑04‑00‑00‑01 |
| Product Type | System Rack for 3500 Machinery Protection Modules |
| Rack Size | 19‑inch EIA Rack, Full‑Size (14 module slots) |
| Module Slots | 14 module slots plus reserved positions for power/interface |
| Mounting Options | Panel mount, Rack mount, Bulkhead mount |
| Format Options | Full‑size rack with flexible front or rear wiring access |
| Backplane Communication | High-speed integrated backplane for module communication |
| Power Distribution | Uniform distribution through the backplane |
| Compatible Modules | 3500 Series monitoring, interface, and power supply modules |
| Installation Flexibility | Supports front or rear access depending on mount type |
| Typical Environments | Control rooms, machinery protection centers, industrial cabinets |
| Build Quality | Engineered for industrial resilience and long service life |
FAQ
A1: It houses and organizes 3500 Series monitoring modules while managing power and data communication.Q2: How many module slots does it support?
A2: This full‑size rack supports 14 slots plus reserved positions for power and interface modules.Q3: What mounting options are available?
A3: Panel mount, rack mount, and bulkhead mount formats support various installation needs.
Q4: Can the system be expanded later?
A4: Yes. The modular design allows adding or replacing modules without extensive rewiring.
Q5: Where is this rack typically installed?
A5: It fits industrial cabinets, control rooms, and machinery protection centers.
Q6: Does it support real‑time module communication?
A6: Yes. The integrated backplane enables high‑speed communication across module slots.
