Overview
Specification
| Parameter | Specification |
|---|---|
| Model | 10100/2/1 |
| Module Type | Bus Driver Module |
| Communication Type | FSC horizontal bus interface |
| Safety Compliance | SIL 2 / SIL 3 capable |
| Operating Voltage | 24 V DC nominal, 20–30 V DC operational range |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature | -50°C to +85°C (-58°F to +185°F) |
| Mounting | FSC standard rack slot |
| Diagnostics | LED indicators for module and bus status |
| Response Time | Deterministic, <5 ms typical |
| Electromagnetic Compatibility | EN 61326-1 compliant |
| Shock & Vibration Resistance | 15 g shock; vibration 5–150 Hz compliant |
| Certifications | CE, SIL, FM approved |
FAQ
Q1: What is the main function of the 10100/2/1 module?
A1: It provides reliable bus driving for FSC horizontal communication between system modules.
Q2: Is the module SIL-certified for safety-critical applications?
A2: Yes, it is SIL 2 / SIL 3 capable to ensure compliance with safety standards.
Q3: What is the operating voltage range?
A3: The module operates from 20–30 V DC, nominal 24 V DC.
Q4: Are diagnostics available for troubleshooting?
A4: Yes, LED indicators provide real-time module and bus status.
Q5: What environments can the module operate in?
A5: It functions reliably between -40°C to +70°C and 5–95% non-condensing humidity.
Q6: Can the module support high-speed data transfer?
A6: Yes, it ensures deterministic, low-latency communication across FSC modules.
