Overview
Configured for galvanically isolated power distribution within Honeywell DCS I/O architecture, the Honeywell MU-KGPR05 (51109620-195) (MU-KGPR05 Power Distribution Cable) provides a factory-terminated connection for controlled cabinet power routing. The assembly has a 195 in (approximately 5 m) cable length and a 300 V AC voltage rating.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MU-KGPR05 |
| Part Number | 51109620-195 |
| Brand | Honeywell |
| Product Type | Galvanic Isolation Power Distribution Cable |
| Application | DCS I/O power distribution and cabinet interconnection |
| Cable Length | 195 in (approximately 5 m) |
| Voltage Rating | 300 V AC |
| Shielding | EMI-resistant shielding |
| Connector Type | Factory-terminated multi-pin connectors |
| Insulation | Flame-retardant insulation |
| System Compatibility | Honeywell DCS I/O Series, PLC, and ESD modules |
| Origin | USA |
| Operating Temp | -20 deg C to +70 deg C |
Galvanic Isolation and DCS Power Distribution
The MU-KGPR05 separates connected power distribution paths electrically to reduce ground-loop effects. Its shielded construction also limits electromagnetic interference during cabinet-level routing.
Furthermore, the 195 in cable length supports routing between separated cabinet connection points and associated I/O hardware. Factory-terminated multi-pin connectors provide a defined physical interface and reduce field termination work.
The assembly uses flame-retardant insulation and industrial jacketing for cabinet installation. However, the supplied data does not define a specific flame rating, conductor gauge, insulation thickness, or connector pin assignment.
Frequently Asked Questions
Q: What is the rated voltage of the MU-KGPR05?
A: The supplied specification lists a voltage rating of 300 V AC.
Q: Does the MU-KGPR05 provide electrical isolation?
A: Yes. The product is specified as a galvanic isolation power distribution cable and is intended to electrically separate associated power paths.
Q: Is the cable length fixed?
A: The supplied specification identifies the cable length as 195 in, approximately 5 m.
Field Installation Guidelines
- Verify the MU-KGPR05 model and part number before installation.
- Confirm the cabinet wiring diagram and connector pin assignment before energizing the circuit.
- Route the cable separately from high-current switching conductors where practical to limit electromagnetic coupling.
- Avoid excessive bending, crushing, or mechanical loading of the cable assembly.
- Maintain connector engagement and secure all applicable mechanical retention features.
- Terminate or bond the cable shield according to the applicable Honeywell cabinet grounding documentation.
- Keep shield routing controlled and avoid creating unintended ground-loop paths.
- Inspect connectors, insulation, and cable jacketing before commissioning.
- Do not exceed the stated 300 V AC voltage rating.
- Confirm the installed operating environment remains within -20 deg C to +70 deg C.
