Overview
The Honeywell FS-SICC-1011/L15, also cataloged as the FS-SICC-1011 System Interconnection Cable, provides a physical interconnection between Honeywell safety I/O hardware and associated termination or interface assemblies. The /L15 version specifies a 15 m cable length.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | FS-SICC-1011/L15 |
| Brand | Honeywell |
| Product Type | System Interconnection Cable (SIC) |
| Cable Length | 15 m |
| Conductor / Wiring | Shielded multi-conductor / twisted-pair construction |
| Voltage Rating | Up to 300 V, as specified for applicable AWM variants |
| Shielding | Foil / braid shield |
| Jacket Material | Industrial PVC / thermoplastic material |
| Operating Temp | -20 deg C to +85 deg C, subject to applicable cable specification |
| Power Consumption | Not applicable; passive interconnection cable |
| Application | Safety I/O and FTA interconnection |
| System Compatibility | Honeywell Safety Manager / RUSIO I/O architecture |
Process Control Signal and Cable Interface
The FS-SICC-1011/L15 carries electrical connections between compatible Honeywell system components through its factory-terminated interface. The shielded construction helps limit electromagnetic coupling between adjacent signal circuits.
For process-control installations, the cable should remain separated from high-energy power conductors where the installation design requires noise control. The cable termination must match the designated Honeywell interface hardware; therefore, installers should verify connector orientation and pin assignment before energizing the connected assembly.
The cable itself does not perform signal conversion, isolation, protocol processing, or loop power generation. It provides the physical conductor path between the connected system interfaces.
Frequently Asked Questions
Q: Is the FS-SICC-1011/L15 an active electronic module?
A: No. It is a passive system interconnection cable and has no stated internal power consumption.
Q: What does the /L15 designation indicate?
A: The supplied specification identifies the /L15 version as a 15 m cable.
Q: Does the cable provide signal isolation?
A: No specific galvanic isolation function is specified for the cable. The stated shielding reduces electromagnetic interference, but it does not replace an electrical isolation device.
Field Installation Guidelines
- Verify the complete FS-SICC-1011/L15 part number before installation.
- Confirm connector type, orientation, and pin assignment against the applicable Honeywell system documentation.
- Route the cable to avoid unnecessary proximity to high-current or high-voltage power wiring.
- Maintain the cable shield according to the system grounding design. Do not create unintended shield-ground loops.
- Avoid excessive bending, crushing, pulling, or twisting during installation.
- Secure the cable so that connector bodies do not carry mechanical tension.
- Inspect connector contacts and cable jackets for physical damage before connection.
- Confirm continuity and correct termination before applying system power
