Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Model Number | FC-DO-1624 |
| Module Type | Digital Output Module |
| Compatibility | Honeywell FSC Series Controllers |
| Output Channels | 16 digital outputs |
| Output Type | Sourcing / Sink switching |
| Output Voltage | 24 V DC nominal |
| Output Current | 0.5–2 A per channel |
| Switching Frequency | Up to 50 Hz |
| Response Time | <5 ms |
| Power Consumption | 5 W typical |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –20°C to 70°C |
| Mounting | DIN rail or panel |
| Diagnostics | LED indicators for channel status |
| Protection Rating | IP20 |
| Dimensions (approx.) | 120 × 100 × 35 mm |
| Weight (approx.) | 0.4 kg |
FAQ
Q1: What controllers is the FC-DO-1624 compatible with?
A1: It is compatible with Honeywell FSC series safety and automation controllers.
Q2: How many digital outputs does the module provide?
A2: The module provides 16 digital output channels.
Q3: What is the response time of the module?
A3: The module responds in under 5 milliseconds for real-time operation.
Q4: Can the module be mounted on a DIN rail?
A4: Yes, it supports both DIN rail and panel mounting for flexibility.
Q5: Does it include diagnostics for troubleshooting?
A5: Yes, LED indicators show channel status for easy fault identification.
Q6: What are the operating temperature limits?
A6: It operates safely from 0°C to 60°C.
