Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-PFE221 |
| Brand | Honeywell |
| Origin | USA |
| Product Type | Fiber Optic Extender Module |
| System Compatibility | Honeywell Experion PKS C300 Controller Series |
| Communication Medium | Fiber optic signal transmission |
| Communication Function | Optical extension of controller network signals |
| Operating Voltage | System supplied power |
| Weight | Approx. 0.2 kg |
| Dimensions | Approx. 100 mm x 100 mm x 30 mm |
| Operating Temp | -40 deg C to +85 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Protection Features | Optical isolation, overvoltage protection, short-circuit protection |
Honeywell Process Control Communication Characteristics
The CC-PFE221 extends Experion PKS C300 communication paths through fiber optic transmission. Therefore, it reduces the influence of electrical interference on signal transfer between separated control cabinets or remote system nodes.
The module applies optical isolation to maintain signal separation between communication interfaces. In addition, Honeywell process control architectures commonly use isolated field communication methods, including 4-20 mA HART loop protocol, FOUNDATION Fieldbus, and Profibus PA connectivity at the I/O level. However, the CC-PFE221 operates as a communication extension component rather than a field measurement interface.
The optical interface supports distributed control installation requirements where copper communication paths may experience electromagnetic noise, ground potential differences, or long-distance transmission limitations.
Frequently Asked Questions
Q: Does the CC-PFE221 provide direct field signal measurement functions?
A: No. The CC-PFE221 operates as a fiber optic extension module and does not perform analog or digital field signal acquisition.
Q: Can the CC-PFE221 replace standard copper communication wiring?
A: The module extends compatible communication links through fiber optic media. Installation must follow the specified Experion PKS C300 system architecture.
Q: What installation considerations apply to the fiber connection?
A: Technicians should maintain proper fiber routing, avoid excessive bending, protect connectors from contamination, and separate fiber paths from mechanical damage sources.
Field Installation Guidelines
- Install the CC-PFE221 according to the Experion PKS C300 hardware configuration requirements.
- Mount the module inside a suitable control cabinet with adequate mechanical support.
- Route fiber optic cables separately from high-voltage power conductors and high-current switching devices.
- Inspect optical connectors before installation and keep termination surfaces clean.
- Use appropriate grounding practices for associated cabinet hardware to reduce electrical noise coupling.
- Verify communication status after installation through the controller configuration and diagnostic functions.
