Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | Honeywell |
| Model Number | CC-PCF901 |
| Module Type | Control Firewall / Network Security Module |
| Compatible System | Experion PKS C300 Distributed Control System |
| I/O Mounting | Standard C300 I/O Chassis Slot |
| Power Supply | Supplied via I/O chassis backplane (nominal 24V DC) |
| Power Consumption | Typical: 3.5 W; Maximum: 5 W |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Communication Interfaces | Redundant fieldbus channels; secure controller links; Modbus/Profinet optional |
| Network Isolation | Yes, separates control network from plant network |
| Data Monitoring | Continuous real-time traffic monitoring with fault detection |
| Diagnostics | Self-check, traffic logs, alarm and security notifications |
| Response Time | Typical latency <5 ms for firewall inspection |
| Throughput | Up to 100 Mbps per communication channel |
| Mounting Dimensions | Standard C300 I/O module width, height, and depth |
| Weight | 0.45 kg (approx.) |
| EMC Compliance | Meets IEC 61326-1 industrial electromagnetic compatibility standards |
| Vibration / Shock | IEC 60068-2-6 vibration; IEC 60068-2-27 shock resistant |
| Certifications | UL, CE, CSA approved for industrial applications |
| Enclosure Rating | Designed to withstand typical I/O chassis environmental conditions |
| Maintenance | Hot-swappable; supports firmware upgrades without system shutdown |
| Reliability | MTBF: 100,000+ hours (typical) |
| Safety Features | Isolation of control and plant networks; traffic anomaly detection |
FAQ
Q: What systems is the CC-PCF901 compatible with?
A: It integrates with Honeywell Experion PKS C300 distributed control systems seamlessly.
Q: Does it provide real-time monitoring?
A: Yes, it continuously monitors communication between controllers and field devices.
Q: Can it operate in harsh environments?
A: Yes, it operates reliably in 0–60°C and 5–95% non-condensing humidity conditions.
Q: How does it enhance system security?
A: The module isolates control networks and detects unauthorized access or traffic anomalies.
