Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | Honeywell |
| Model Number | 8C-PAINA1 |
| Part Number | 51454470-175 |
| Product Type | Single-Ended Analog Input Module |
| Compatible System | Experion PKS C300 Distributed Control System |
| Input Signal Types | 4–20 mA, 0–20 mA, thermocouple, RTD |
| Number of Channels | 16 single-ended channels per module |
| Input Voltage Range | 0–10 V nominal |
| Input Current Range | 4–20 mA, 0–20 mA |
| Accuracy | ±0.05% of full scale typical |
| Isolation | Channel-to-channel isolation for noise immunity |
| Input Scan Rate | 50 ms per channel typical |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | ‑40°C to +85°C (‑40°F to 185°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Mounting | Experion PKS C300 I/O chassis |
| Diagnostics | Open sensor detection, fault alarms |
| Protective Coating | Conformal coating for enhanced environmental resistance |
FAQ
Q: What sensor types does the 8C-PAINA1 support?
A: It supports 4–20 mA, 0–20 mA, thermocouple, and RTD sensors.
Q: Can this module operate in high-humidity environments?
A: Yes, the conformal coating and robust design allow operation in 5%–95% non-condensing humidity.
Q: How does the module integrate with Experion PKS C300?
A: The module plugs directly into the C300 I/O chassis and communicates with controllers seamlessly.
Q: Does it provide fault detection?
A: Yes, it offers open sensor detection and diagnostic alarms for proactive maintenance.
