Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | 900G32-0101 |
| Series | FSC (Field System Controller) |
| Module Type | Digital Input Module |
| Number of Inputs | 32 digital inputs |
| Input Type | Sourcing or sinking configurable |
| Input Voltage Range | 24 VDC nominal |
| Response Time | 1 ms typical |
| Isolation | Channel-to-channel and channel-to-backplane |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5–500 Hz, 0.5 g RMS |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Mounting | FSC backplane compatible; optional DIN rail |
| Dimensions | 120 mm x 100 mm x 40 mm (approx.) |
| Weight | 0.9 kg (approx.) |
| Compliance / Certification | CE, UL, CSA, RoHS |
| Maintenance | Hot-swappable with built-in diagnostics for preventive maintenance |
FAQ
Q1: How many digital input channels does this module provide?
A1: The 900G32-0101 provides 32 digital input channels for versatile process monitoring.
Q2: What type of input signals does the module support?
A2: It supports sourcing or sinking digital input signals configurable per application.
Q3: Can the module operate in harsh industrial environments?
A3: Yes, it withstands vibration, shock, temperature extremes, and non-condensing humidity.
Q4: Is this module compatible with existing FSC controllers?
A4: Absolutely, it integrates seamlessly with FSC backplane systems.
Q5: Can modules be replaced without shutting down the system?
A5: Yes, the 900G32-0101 is hot-swappable, allowing maintenance without operational downtime.
Q6: Does the module support diagnostics and preventive maintenance?
A6: Yes, built-in diagnostics monitor input status, simplifying preventive maintenance.
