Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | 900R12-0200 |
| Series | FSC (Field System Controller) |
| Module Type | I/O Rack – 12 Slot |
| Slot Capacity | 12 FSC I/O module slots |
| Backplane Interface | FSC backplane communication |
| Power Supply | 24 VDC nominal, 15 W typical per rack |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5–500 Hz, 0.5 g RMS |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Mounting | 19-inch rack compatible; optional DIN rail |
| Dimensions | 430 mm x 150 mm x 60 mm (approx.) |
| Weight | 3.2 kg (approx.) |
| Compliance / Certification | CE, UL, CSA, RoHS |
| Maintenance | Hot-swappable slots simplify preventive maintenance procedures |
FAQ
Q1: How many I/O modules can this rack support?
A1: The 900R12-0200 supports up to twelve FSC I/O modules for flexible system expansion.
Q2: Can modules be replaced without shutting down the system?
A2: Yes, all slots are hot-swappable to allow maintenance without operational downtime.
Q3: Is the rack suitable for harsh industrial environments?
A3: Absolutely, it is designed to withstand vibration, shock, and temperature extremes.
Q4: Can this rack integrate with redundant FSC configurations?
A4: Yes, it supports FSC backplane and redundant system setups for higher reliability.
Q5: What types of modules are compatible with this rack?
A5: It supports all FSC analog and digital input/output modules for versatile integration.
Q6: How does the rack handle diagnostics and preventive maintenance?
A6: Built-in diagnostics continuously monitor module status and simplify preventive maintenance procedures.
