Overview
It provides reliable relay outputs for alarms, trips, and auxiliary functions, ensuring continuous protection of critical rotating equipment.
Engineers deploy 3500/32 125712-01 to expand relay capacity or replace aging modules in turbines, compressors, and generators.
This module supports fast relay actuation with precise timing, integrating seamlessly with Bently Nevada 3500 Series cards.
Technicians install 3500/32 125712-01 directly into a standard 3500 rack slot, minimizing downtime during maintenance.
Specification
| Parameter | Specification |
|---|---|
| Model | 3500/32 125712-01 |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection System |
| Module type | 4-Channel Relay Module |
| Number of relays | 4 independent relay channels |
| Relay contact type | SPDT (Single-Pole Double-Throw), NO/NC contacts |
| Contact rating | 2 A @ 30 VDC or 0.5 A @ 125 VAC |
| Trigger type | Alarm, trip, auxiliary signal input from 3500 rack |
| Input interface | Internal rack bus, monitoring card signals |
| Slot type | Standard 3500 rack module |
| Front indicators | Power LED, Channel A-D status LEDs |
| Operating temperature | 0°C to +65°C |
| Storage temperature | −40°C to +85°C |
| Relative humidity | 95% non-condensing |
| Module height | 120.7 mm |
| Module width | 25.4 mm |
| Module depth | 241 mm |
| Approximate weight | 0.35 kg |
| Power consumption | Approximately 6 W |
| Energy storage | None, no internal batteries or capacitors |
| Mounting | Direct insertion into 3500 rack backplane |
| Typical applications | Turbines, compressors, generators, pumps, critical rotating machinery |
FAQ
A1: Yes, 3500/32 125712-01 ships as factory-new, original equipment from Bently Nevada.
Q2: Do you have the module in stock?
A1: Yes, 3500/32 125712-01 is available in stock for immediate order processing.
Q3: How fast do you ship 3500/32 125712-01?
A1: We ship within three days to two weeks, depending on order size and destination.
Q4: Which logistics carriers are used?
A1: DHL and other reliable international express services typically handle shipping.
Q5: What if there is a quality issue?
A1: We support returns for 3500/32 125712-01 within thirty days in case of any quality problems.
Q6: Can I use this module with older 3500 racks?
A1: Yes, 3500/32 125712-01 is fully compatible with existing Bently Nevada 3500 Series racks and monitoring cards.
