Overview
Specification
| Parameter | Specification |
|---|---|
| Module Model | 3500/94 – Part Number 145988-01 |
| Module Type | VGA Display Monitor Module |
| Display Interface | Standard VGA video output |
| Supported Resolution | Up to 1024 × 768 |
| Displayed Information | Channel data, alarms, statuses, system overview |
| Display Pages | Overview, channel detail, alarm list, system status |
| Refresh Rate | Real-time update synchronized with rack data cycle |
| Communication Interface | Internal 3500 rack data bus |
| Compatible System | Fully compatible with Bently Nevada 3500 Series |
| User Interface | On-screen menus with simple navigation |
| Alarm Indications | OK, Not OK, Alert, Danger |
| Power Supply Source | Powered through 3500 rack backplane |
| Power Consumption | Low-power module design |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Humidity Range | Up to 95% non-condensing |
| EMC Compliance | Meets industrial electromagnetic compatibility standards |
| Safety Rating | Compliant with global industrial safety regulations |
| Installation Method | Standard 3500 module slot installation |
| Module Dimensions | Standard 3500 card form factor |
| Module Weight | Lightweight modular design |
FAQ
A1: It shows vibration measurements, alarm statuses, channel information, and overall machine health data in real time.
Q2: Does this module require a specific type of monitor?
A2: It supports standard VGA monitors, allowing flexible installation in most control rooms.
Q3: Can it integrate with any 3500 rack configuration?
A3: Yes, the module works with all standard Bently Nevada 3500 systems and communicates directly with other rack modules.
Q4: How often does the data refresh on the screen?
A4: Data updates occur continuously, providing real-time visibility based on rack activity.
Q5: Is this module suitable for high-temperature environments?
A5: The module operates reliably within 0°C to +65°C, covering most industrial control locations.
Q6: Does it store historical data?
A6: The module displays data only; long-term storage is handled by external condition monitoring software.
