Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/15-05-05-05 (106M1079-01 + 106M1081-01) |
| Module Type | Universal AC Power Supply Module |
| Input Voltage Range | 85–264 VAC, single-phase, 47–63 Hz |
| Input Current | 2.0 A maximum at 120 VAC; 1.0 A maximum at 240 VAC |
| Input Protection | Fused input, surge suppression, transient voltage protection |
| Output Voltage | 125 VDC nominal |
| Output Current | 1.2 A continuous per module |
| Output Power | 150 W maximum |
| Load Regulation | ±1% typical at full load |
| Line Regulation | ±0.5% typical |
| Ripple & Noise | <100 mV peak-to-peak |
| Efficiency | 85–90% typical at nominal load |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5%–95%, non-condensing |
| Dimensions (H × W × D) | 12.7 cm × 7.6 cm × 20.3 cm (5″ × 3″ × 8″) |
| Weight | 2.3 kg (5.1 lbs) |
| Mounting | Standard 3500 system rack, front-panel installation |
| Cooling | Convection-cooled; no fan required |
| Safety Features | Overvoltage protection, overload protection, thermal shutdown |
| Compliance & Certifications | CE, UL, CSA, and ISO 9001 standards |
| Connectors | Input: screw terminals; Output: plug-in rack interface |
| Energy Storage | Internal capacitors provide short-term hold-up during transient dips |
| Service Life | Designed for continuous industrial operation, ≥10 years typical |
| Environmental Rating | IEC 60529 IP20 (rack-mounted, indoor use) |
| MTBF | 100,000 hours typical at rated conditions |
| Operational Notes | Compatible with 3500 system modules including proximity, vibration, and relay units; maintains continuous regulated DC voltage under variable load conditions |
FAQ
A1: Yes, this module is 100% factory-new and original, manufactured by Bently Nevada.
Q2: What is the typical delivery time for this power supply module?
A2: We usually ship within 3 days to 2 weeks depending on order size, using standard carriers like DHL.
Q3: Which voltage inputs does this universal AC power supply support?
A3: It supports multiple AC voltage inputs, providing flexible operation for various industrial setups.
Q4: Can this module integrate into standard 3500 system racks?
A4: Yes, the module fits seamlessly into all standard 3500 system racks, ensuring stable power delivery.
Q5: What should I do if the module has a quality issue after delivery?
A5: We support returns within 30 days if the product has any manufacturing defects or quality issues.
Q6: How does this module improve overall system reliability?
A6: Its robust design reduces energy losses, stabilizes voltage, and ensures continuous, reliable power to all channels.
