Overview
The 3500/05 rack supports front-loading modules, allowing quick installation and service without removing system wiring. Therefore, it minimizes downtime while ensuring mechanical stability and high system availability.
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/05-02-04-00-00-00 |
| Brand | Bently Nevada (GE) |
| Product Type | 3500 System Rack |
| Rack Size | 12-inch Mini-Rack (7 module slots) |
| Module Mounting | Front-loading with secure locking retention |
| Mounting Options | Panel Mount Option (Mini-Rack configuration) |
| Power Supply Options | Dual redundant AC or DC power inputs |
| Communication Interface | Compatible with 3500/22M Transient Data Interface and 3500/20 Rack Interface Module |
| Backplane Design | Integrated signal and power distribution for module interconnection |
| Cooling Method | Natural convection (no external fan required) |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | Up to 95%, non-condensing |
| Dimensions (W × H × D) | Approx. 304.8 mm × 266.7 mm × 279.4 mm |
| Weight | Approx. 6.8 kg (fully equipped rack) |
| Material Construction | Aluminum chassis with corrosion-resistant finish |
| Compliance | CE, CSA, ATEX/IECEx, ISO 9001 compliant |
| Typical System Modules | Supports monitoring, power supply, and interface modules |
| Serviceability | Front-access design for easy installation and maintenance |
FAQ
A1: The mini-rack supports up to seven full-height modules, excluding power and interface positions.
Q2: Can I use the mini-rack in a 19-inch EIA cabinet?
A2: Yes, by using the 144863-01 EIA Adapter Panel, the mini-rack can be mounted in standard 19-inch racks.
Q3: What type of power input does the rack support?
A3: The rack supports dual redundant AC or DC power supply modules for increased reliability.
Q4: Which interface modules are compatible with this rack?
A4: The 3500/22M Transient Data Interface and the 3500/20 Rack Interface Module are fully supported.
Q5: Is this model suitable for hazardous environments?
A5: Yes, it meets ATEX and IECEx certifications for installation in Class 1, Zone 2 environments.
