Overview
The Bently Nevada 3500/05-01-01-00-00-01 System Rack provides the core physical structure for the 3500 Machinery Protection System.
It securely houses monitoring modules, power supplies, and communication interfaces in a standardized industrial rack format.
Moreover, the rack ensures precise electrical alignment through an integrated backplane design for stable system performance.
Therefore, engineers rely on this rack to maintain reliable signal integrity and long-term operational stability in critical applications.
It serves as the foundation for building scalable and high-performance machinery protection architectures.
Key Features and Functional Highlights
The rack supports multiple plug-in modules, enabling flexible configuration based on machinery monitoring requirements.
In addition, it provides a robust backplane that distributes power and communication signals efficiently across all modules.
Engineers can expand system capacity easily without redesigning the entire protection architecture.
Moreover, the rack design improves installation speed and reduces wiring complexity during commissioning.
Furthermore, clear slot labeling ensures accurate module placement and simplifies maintenance procedures.
Specification
| Parameter | Description |
|---|---|
| Model | 3500/05 System Rack |
| Configuration Code | 3500/05-01-01-00-00-01 |
| System Type | Machinery Protection System Rack |
| Module Capacity | Supports multiple monitoring, power, and interface modules |
| Rack Size | Standard 19-inch industrial rack format |
| Backplane Type | Integrated power and signal distribution backplane |
| Power Supply Support | Single or redundant power supply configurations |
| System Compatibility | Bently Nevada 3500 Machinery Protection System |
| Mounting Style | Rack-mounted or panel-mounted installation options |
| Construction Material | Industrial-grade metal chassis for high durability |
| Cooling Method | Natural convection airflow design |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
FAQ
Q1: What is the main purpose of the 3500/05 system rack?
A1: It provides the structural and electrical foundation for the Bently Nevada 3500 monitoring system.
Q2: How many modules can the rack support?
A2: It supports multiple modules, including monitoring, power supply, and communication units.
Q3: Does the rack support redundant power configurations?
A3: Yes, it supports both single and redundant power supply setups.
Q4: Is it compatible with all 3500 system modules?
A4: Yes, it is fully compatible with standard Bently Nevada 3500 system components.
