Configured for UCN network signal transmission in Honeywell control architectures, the Honeywell MU-NKT020 (MU-NKT020 UCN Trunk Cable Assembly) provides direct physical connection between network interface components and termination assemblies. The full part number is 51195199-020, with a 20 m cable length designed for TDC 3000 and Experion PKS HPM systems.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MU-NKT020 |
| Brand | Honeywell |
| Origin | United States |
| Part Number | 51195199-020 |
| Component Type | UCN Trunk Cable Assembly / Network Connection Kit |
| Compatible Systems | Honeywell TDC 3000, Experion PKS, High-Performance Process Manager (HPM) |
| Network Protocol | Universal Control Network (UCN) |
| Cable Length | 20 m |
| Cable Construction | Shielded industrial communication cable assembly |
| Signal Type | UCN digital communication signal |
| Operating Temp | 0 deg C to +60 deg C |
| Dimensions | 20 m cable assembly length; physical package dimensions not specified |
| Power Consumption | Passive cable assembly; no external power consumption |
UCN Network Signal Integrity Characteristics
The MU-NKT020 uses a shielded cable construction to maintain UCN communication performance between Honeywell network components. The shielding layer reduces electromagnetic interference and radio frequency interference effects during digital signal transmission.
Furthermore, the cable assembly provides a pre-terminated connection method for Honeywell UCN architectures. It supports direct installation between Network Interface Modules, controllers, and termination assemblies without additional field termination work.
The cable does not process analog instrumentation signals such as 4-20 mA HART loops. Instead, it transfers digital network communication data within Honeywell distributed control system architectures. Therefore, installation focuses on cable routing, shielding continuity, and connector protection.
Frequently Asked Questions
Q: What Honeywell systems support the MU-NKT020 cable assembly?
A: The MU-NKT020 supports Honeywell UCN-based architectures, including TDC 3000 and Experion PKS systems with High-Performance Process Manager configurations.
Q: Does the MU-NKT020 require external power or configuration firmware?
A: No. The MU-NKT020 is a passive cable assembly and does not contain electronic circuits, firmware, or power conversion components.
Q: What installation practices should be applied for UCN cable performance?
A: Installers should maintain shield continuity, avoid routing near high-noise power conductors, and protect connectors from mechanical stress and contamination.
Field Installation Guidelines
- Verify the cable model and part number before connection to the UCN network equipment.
- Route the cable separately from high-current motor power cables and variable frequency drive output conductors.
- Maintain the cable shielding path through the complete communication route to reduce electromagnetic interference.
- Avoid sharp bending, excessive pulling force, and mechanical stress on connectors during installation.
- Secure the cable assembly inside control cabinets or cable trays to prevent movement and connector loading.
- Confirm connector engagement before system startup and verify UCN communication status through the associated Honeywell control system diagnostics.
