Overview
Configured for mechanical module accommodation and system backplane integration in Honeywell distributed control system architectures, the Honeywell MC-HPFX02 (MC-HPFX02 Right 7-Slot HPMM Card File Assembly) provides direct physical support for compatible control, I/O, and communication hardware. The right-side card file configuration provides seven module positions and supports organized hardware installation within the applicable Honeywell modular control assembly.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MC-HPFX02 |
| Brand | Honeywell |
| Module Type | Right 7-Slot High Performance Modular Matrix Card File Assembly |
| Slot Count | 7 slots |
| Configuration | Right-side card file configuration |
| Technology | High Performance Modular Matrix |
| Application | Industrial Control Systems and Distributed Control Systems |
| Weight | Approx. 0.2 kg to 0.5 kg |
| Dimensions | Approx. 180 mm x 100 mm x 30 mm; variant dimensions may differ |
| Operating Temp | -20 deg C to +70 deg C |
| Storage Temp | -40 deg C to +85 deg C |
| Power Consumption | Max. 25 W |
| Certifications | CE, UL, FCC listed in the provided specification; applicability depends on the supplied assembly variant |
DCS Module Accommodation and Process Signal Infrastructure
The MC-HPFX02 functions as a physical card file assembly rather than a process signal measurement channel. Therefore, the assembly itself does not directly execute 4-20 mA HART signal conversion or channel-to-channel isolation.
Instead, the installed Honeywell modules determine the electrical characteristics of the completed assembly. Depending on the compatible module population, the associated control architecture may support process instrumentation functions such as analog signal handling, HART communication, field termination, and isolated channel interfaces.
The seven-slot mechanical arrangement allows compatible hardware modules to occupy defined positions within the card file. Consequently, system signal handling and communication capabilities depend on the installed controller, I/O, communication, or interface modules and their associated backplane connections.
Frequently Asked Questions
Q: Does the MC-HPFX02 itself process 4-20 mA or HART signals?
A: No. The MC-HPFX02 is specified as a card file assembly. Process signal processing depends on the compatible modules installed within the available card positions.
Q: Can any Honeywell module be installed in the seven slots?
A: Compatibility must be verified against the applicable Honeywell hardware architecture. Mechanical fit alone does not confirm electrical, backplane, or system compatibility.
Q: Does the provided specification confirm hot-swap capability?
A: No specific hot-swap specification is provided for the MC-HPFX02 assembly. Module insertion or removal procedures should therefore follow the requirements of the associated Honeywell system documentation.
Field Installation Guidelines
- Install the MC-HPFX02 on a rigid mounting surface that supports the specified card file orientation.
- Verify mechanical clearance before inserting compatible modules into the seven available positions.
- Keep module connectors and backplane contact areas free from contamination and mechanical damage.
- Confirm that each installed module matches the applicable Honeywell system hardware configuration.
- Route field wiring and communication cables separately where the system installation standard requires signal segregation.
- Maintain appropriate shielding and grounding practices for analog and communication circuits connected through installed modules.
- Disconnect or isolate system power when the applicable hardware procedure requires module or card file replacement.
- Verify all mechanical fasteners and module retention points before system energization.
- Confirm the complete operating temperature range against the actual enclosure and cabinet environment.
