Overview
The MC-TAOY22 51204172-175 from Honeywell delivers precise analog signal output for advanced industrial control systems.
It converts digital control signals into stable analog outputs, which ensures accurate actuator and process control performance.
Moreover, the module integrates seamlessly within Honeywell UCN systems, providing consistent communication and reliable signal transmission.
Engineers rely on MC-TAOY22 51204172-175 for its accuracy, durability, and efficient signal conversion capabilities.
Specification
| Parameter | Specification |
|---|---|
| Model | MC-TAOY22 51204172-175 |
| Manufacturer | Honeywell |
| Product Type | Analog Output Module |
| Series | Honeywell UCN (Universal Control Network) |
| Output Channels | 8 analog output channels |
| Output Signal Type | 4–20 mA current output |
| Output Range | 0–20 mA configurable |
| Load Resistance | Up to 750 Ω |
| Resolution | 12-bit digital-to-analog conversion |
| Accuracy | ±0.1% of full scale |
| Update Rate | Real-time output refresh ≤ 10 ms |
| Isolation Type | Channel-to-system isolation |
| Isolation Voltage | Up to 1500V AC |
| Interface | UCN backplane communication |
| Connector Type | Terminal block for field wiring |
| Power Supply | Backplane powered |
| Power Consumption | ≤ 6W typical |
| Heat Dissipation | Low thermal output design |
| Dimensions (L × W × H) | Approx. 160 × 120 × 50 mm |
| Weight | Approx. 0.55 kg |
| Mounting Method | Rack-mounted module |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| EMC Compliance | Meets industrial EMC standards |
| Protection Features | Overcurrent protection and noise filtering |
| LED Indicators | Channel status and diagnostics LEDs |
| Wiring Method | Screw terminal connections |
| Redundancy Support | Compatible with redundant control systems |
FAQ
Q1: What output signal does the module provide?
The MC-TAOY22 51204172-175 provides 4–20 mA analog output signals across eight independent channels.
Q2: What is the maximum load resistance supported?
The MC-TAOY22 51204172-175 supports load resistance up to 750 ohms for stable signal transmission.
Q3: What is the delivery time for this module?
We keep MC-TAOY22 51204172-175 in stock, and we ship within 3 days to 2 weeks.
Q4: Which shipping methods do you use?
We usually deliver MC-TAOY22 51204172-175 through DHL and other reliable logistics providers.
Q5: Can I return the product if quality issues occur?
Yes, we support returns within 30 days if any quality issue occurs after delivery.
Q6: Is the product new and original?
We supply MC-TAOY22 51204172-175 as brand new, original, and factory-sealed inventory.
