Overview
The FC-TSDI-16UNI Honeywell FSC Series Safe Digital Input FTA Module delivers high-reliability input monitoring for safety-critical industrial systems. Moreover, it ensures precise signal acquisition from field devices, enabling fast and accurate fault detection. Therefore, this module significantly improves system safety while maintaining seamless integration with FSC controllers.
Specification
| Parameter | Specification |
|---|---|
| Model | FC-TSDI-16UNI |
| Manufacturer | Honeywell |
| Series | FSC (Fail Safe Controller) Series |
| Module Type | Safe Digital Input FTA Module |
| Digital Channels | 16 individually monitored input channels |
| Input Voltage | 24 V DC nominal |
| Input Type | Loop-monitored digital input |
| Response Time | <10 ms typical per channel |
| Communication Interface | FSC system backplane connector |
| Diagnostics | Channel status, fault detection, open/short monitoring |
| Mounting | FSC chassis compatible, DIN rail optional |
| Dimensions (W × H × D) | Approx. 135 × 120 × 75 mm |
| Weight | Approx. 0.68 kg |
| Operating Temperature | –5 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95%, non-condensing |
| Typical Applications | Emergency shutdown, safety interlocks, monitoring critical signals |
| System Compatibility | Honeywell FSC Series Safety Manager systems |
FAQ
Q1: What is the main purpose of the FC-TSDI-16UNI module?
A1: The FC-TSDI-16UNI monitors 16 digital input channels for safety-critical FSC systems.
Q2: Can it integrate with all FSC controllers?
A2: Yes, it connects directly to Honeywell FSC Series Safety Manager systems.
Q3: What is the typical response time of each channel?
A3: Each channel responds in less than 10 milliseconds, allowing fast detection.
Q4: Does it require external power?
A4: No, the module draws power from the FSC system backplane.
Q5: Are these units brand new and factory original?
A5: Yes, all FC-TSDI-16UNI modules are original Honeywell, factory-new products.
Q6: How long does shipping take and what is the return policy?
A6: Shipping occurs within 3 days to 2 weeks depending on order size, with 30-day returns for quality issues.
