Overview
Moreover, it supports multiple input and output types, enabling engineers to standardize I/O across diverse applications.
This module integrates seamlessly with FSC Series racks and CPUs, ensuring deterministic performance and reliable communication.
In addition, its robust design guarantees long-term stability and consistent operation in demanding process environments.
The universal functionality allows flexible deployment in both new installations and system expansions.
Specification
| Parameter | Specification |
|---|---|
| Model | Honeywell 900U02-0100 |
| Module Type | Universal Input/Output (I/O) |
| Input Types | Analog: 0-20 mA, 4-20 mA, 0-10 V; Digital: TTL, contact closure |
| Output Types | Analog: 0-20 mA, 4-20 mA, 0-10 V; Digital: relay, transistor |
| Input Impedance | 250 Ω typical for current inputs, 100 kΩ for voltage inputs |
| Resolution | 16-bit A/D and D/A conversion |
| Accuracy | ±0.1% of full scale (typical) |
| Update Rate | 10–50 ms per channel, configurable per module |
| Isolation | Galvanic isolation between input, output, and logic |
| Module Mounting | FSC Series backplane rack mount |
| Power Consumption | 3.5 W typical |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 70°C |
| Relative Humidity | 5%–95% non-condensing |
| Communication Interface | FSC backplane, supports deterministic signal updates |
| Fault Handling | Module supports fail-safe and diagnostic signaling |
| Typical Applications | Process automation, hybrid analog/digital control, signal consolidation |
FAQ
Q1: What types of inputs does the 900U02-0100 module support?
A1: It supports universal analog inputs (voltage, current) and digital signals for versatile applications.
Q2: Can this module provide both analog and digital outputs?
A2: Yes, it delivers precise analog outputs and reliable digital outputs for process control.
Q3: Is the module compatible with Honeywell FSC racks and CPUs?
A3: Yes, it integrates seamlessly into FSC Series racks for deterministic communication and control.
Q4: What is the operating temperature range for this module?
A4: It operates reliably from 0°C to 60°C in industrial environments.
Q5: How accurate are the analog conversions?
A5: The module provides ±0.1% full-scale accuracy with 16-bit A/D and D/A resolution.
Q6: Does it support fail-safe or diagnostic features?
A6: Yes, it supports fail-safe operation and diagnostic signaling for enhanced reliability.
