Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | 900RSM-0101 |
| Series | FSC (Field System Controller) |
| Module Type | Redundant Switch Module |
| Redundant Support | Yes, supports redundant FSC network configurations |
| Network Ports | 4 Ethernet ports (10/100 Mbps) |
| Backplane Interface | FSC backplane for controller communication |
| Power Supply | 24 VDC nominal, 5 W typical |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5–500 Hz, 0.5 g RMS |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Mounting | 19-inch rack compatible; optional DIN rail |
| Dimensions | 150 mm x 120 mm x 40 mm (approx.) |
| Weight | 0.9 kg (approx.) |
| Compliance / Certification | CE, UL, CSA, RoHS |
| Maintenance | Hot-swappable; built-in diagnostics for preventive maintenance |
FAQ
Q1: Does this module support redundant FSC network configurations?
A1: Yes, the 900RSM-0101 ensures continuous communication even if one network path fails.
Q2: Can it be installed without shutting down the system?
A2: Yes, the module is hot-swappable, allowing engineers to replace or install it without interrupting operations.
Q3: How many network ports does this module provide?
A3: It provides 4 Ethernet ports supporting 10/100 Mbps connections for FSC controllers.
Q4: Is it suitable for harsh industrial environments?
A4: Absolutely, it is designed to withstand vibration, shock, and wide temperature ranges.
Q5: How does the module handle diagnostics and fault detection?
A5: Built-in diagnostics continuously monitor network and module status, alerting engineers to potential issues.
Q6: What systems can this module integrate with?
A6: It is fully compatible with FSC controllers, backplane communication, and Experion automation architectures.
